Fluke 714B Thermocouple Calibrator

Date:2017-10-26      Category:Electrical Tester

Highly accurate, easy-to-use single function thermocouple temperature calibrator

 For the temperature calibration professional who wants a highly accurate, easy-to-use, single function thermocouple temperature calibrator the Fluke 714B is the ideal test tool.


  • The 714B can measure and simulate (17) different thermocouple types and millivolts
  • Measure 4 to 20 mA signals while simultaneously sourcing a temperature signal
  • Hanging tool designed in and included with every unit
  • Configurable 0 % and 100 % source settings for quick 25 % linearity checks
  • Linear ramp and 25 % step auto ramp based on 0 % and 100 % settings
  • Dual inputs and backlit display for easy interpretation of measurements
  • Power down settings remembered at power up for easy restart of tests
  • 1-year and 2-year specifications and traceable certification of calibration
General Specifications
Maximum voltage applied between any terminal and earth ground or between any two terminals 30 V
Operating temperature -10 °C to 50 °C
Storage temperature - 30 °C to 60 °C
Operating altitude 2,000 meters
Storage altitude 12,000 meters
Relative humidity (% RH operating without condensation) Non condensing
90 % (10 °C to 30 °C)
75 % (30 °C to 40 °C)
45 % (40 °C to 50 °C)
(Without condensation)
Vibration requirements MIL-T-28800E, Class 2
Drop text requirements 1 meter
IP Rating IEC 60529: IP52
Electromagnetic environment IEC 61326-1, Portable
Safety IEC 61010-1, Max 30 V to earth, Pollution Degree 2
Power supply 4 AA NEDA 1.5A IEC LR6 batteries
Size (H x W x L) 52.5 mm x 84 mm x 188.5 mm
Weight 515 g
DC mA Measurement
Resolution Range Accuracy (% of reading + counts)
0-24 mA 0.001 mA 0.010 % + 2 μA
Temperature coefficient ± (0.002 % of reading + 0.002 % of range) /°C ( <18 °C or >28 °C)
Millivolt Measurement and Source
Resolution Range Accuracy (% of reading +counts)
-10 mV to 75 mV 0.01 mV 0.015 % + 10 μA
Temperature coefficient ± (0.002 % of reading + 0.002 % of range) /°C ( <18 °C or >28 °C)
Thermocouple Input and Output
TC Type Range (°C) Measure (°C) Source (°C)
1 year 2 year 1 year 2 year
E -250 to 200 °C 1.3 2.0 0.6 0.9
-200 to -100 °C 0.5 0.8 0.3 0.4
-100 to 600 °C 0.3 0.4 0.3 0.4
600 to 1000 °C 0.4 0.6 0.2 0.3
N -200 to -100 °C 1.0 1.5 0.6 0.9
-100 to 900 °C 0.5 0.8 0.5 0.8
900 to 1300 °C 0.6 0.9 0.3 0.4
J -210 to -100 °C 0.6 0.9 0.3 0.4
-100 to 800 °C 0.3 0.4 0.2 0.3
800 to 1200 °C 0.5 0.8 0.3 0.3
K -200 to -100 °C 0.7 1.0 0.4 0.6
-100 to 400 °C 0.3 0.4 0.3 0.4
400 to 1200 °C 0.5 0.8 0.3 0.4
1200 to 1372 °C 0.7 1.0 0.3 0.4
T -250 to -200 °C 1.7 2.5 0.9 1.4
-200 to 0 °C 0.6 0.9 0.4 0.6
0 to 400 °C 0.3 0.4 0.3 0.4
B 600 to 800 °C 1.3 2.0 1.0 1.5
800 to 1000 °C 1.0 1.5 0.8 1.2
1000 to 1820 °C 0.9 1.3 0.8 1.2
R -20 to 0 °C 2.3 2.8 1.2 1.8
0 to 100 °C 1.5 2.2 1.1 1.7
100 to 1767 °C 1.0 1.5 0.9 1.4
S -20 to 0 °C 2.3 2.8 1.2 1.8
0 to 200 °C 1.5 2.1 1.1 1.7
200 to 1400 °C 0.9 1.4 0.9 1.4
1400 to 1767 °C 1.1 1.7 1.0 1.5
C 0 to 800 °C 0.6 0.9 0.6 0.9
800 to 1200 °C 0.8 1.2 0.7 1.0
1200 to 1800 °C 1.1 1.6 0.9 1.4
1800 to 2316 °C 2.0 3.0 1.3 2.0
L -200 to -100 °C 0.6 0.9 0.3 0.4
-100 to 800 °C 0.3 0.4 0.2 0.3
800 to 900 °C 0.5 0.8 0.2 0.3
U -200 to 0 °C 0.6 0.9 0.4 0.6
0 to 600 °C 0.3 0.4 0.3 0.4
BP 0 to 1000 °C 1.0 1.5 0.4 0.6
1000 to 2000 °C 1.6 2.4 0.6 0.9
2000 to 2500 °C 2.0 3.0 0.8 1.2
XK -200 to 300 °C 0.2 0.3 0.2 0.5
300 to 800 °C 0.4 0.6 0.3 0.6
G 100 to 300 °C 1.6 2.4 1.2 1.8
300 to 1500 °C 1.0 1.5 1.0 1.5
1500 to 2320 °C 2.0 3.0 1.6 2.4
D 0 to 300 °C 1.6 2.4 1.2 1.8
300 to 1500 °C 1.0 1.5 1.0 1.5
1500 to 2315 °C 2.0 3.0 1.6 2.4
P 0 to 1000 °C 1.6 2.4 0.6 0.9
1000 to 1395 °C 2.0 3.0 0.8 1.2
M -50 to 100 °C 1.0 1.5 0.4 0.6
100 to 1000 °C 1.6 2.4 0.6 0.9
1000 to 1410 °C 2.0 3.0 0.8 1.2
